Key Features

??Built-in D-Link Green Technology
??Inexpensive Gigabit solution for Home/
SOHO
??Eight 10/100/1000 Mbps Gigabit ports
??16 Gbps switching fabric
??Auto MDI/MDIX crossover for all ports
??Secure store-and-forward switching
scheme
??Full/half-duplex for Ethernet/Fast
Ethernet speeds
??IEEE 802.3x Flow Control
??Supports 9,216 Byte Jumbo Frames
??RoHS compliant
??Plug-and-play installation

Standards

??IEEE 802.3 10BASE-T Ethernet (twistedpair
copper)
??IEEE 802.3u 100BASE-TX Fast Ethernet
(twisted-pair copper)
??IEEE 802.3ab 1000BASE-T Gigabit
Ethernet (twisted-pair copper)
??ANSI/IEEE 802.3 NWay auto-negotiation
??IEEE 802.3x Flow Control

Protocol

??CSMA/CD

Data Transfer Rates

??Ethernet:
??10 Mbps (half duplex)
??20 Mbps (full duplex)
??Fast Ethernet:
??100 Mbps (half duplex)
??200 Mbps (full duplex)
??Gigabit Ethernet:
??2000 Mbps (full duplex)

Topology

Star

Network Cables

??10BASE-T:
??UTP CAT 3, 4, 5/5e (100 m max.)
??EIA/TIA-586 100-ohm STP (100 m max.)
??100BASE-TX, 1000BASE-T:
??UTP CAT 5/5e (100 m max.)
??EIA/TIA-568 100-ohm STP (100 m max.)

Media Interface Exchange

??Auto MDI/MDIX adjustment for all ports

LED Indicators

??Per port: Link/Activity/Speed
??Per device:power

Transmission Method

??Store-and-forward

MAC Address Tab le

??8K entries per device

MAC Address Learning

??Automatic update

Packet Filtering/Forwa rding Rates

??Ethernet: 14,880 pps per port
??Fast Ethernet: 148,800 pps per port
??Gigabit Ethernet: 1,488,000 pps per port

RAM Buffer

??128 KBytes per device

DC Input

??Switching 5V/1A Level “V” Power

Adapter

Power Consumption
??Power On (Standby):
??AC input: 2.2 watts
??Maximum:
??AC input: 4.8 watts
